| Illumination Type | Side-Lit (Horizontal Bending) | |||
| LED Colour | Fixed White | Tunable White | RGBW | |
| CCT/Wavelength | White: 3000K, 4000K | 2200K-5700K | Red: 618-624nm Green: 522-528nm Blue: 468-474nm White: 3000K | |
| Delivered Lumens | 700lm/m | 300lm/m | 600lm/m | |
| Power | 12W/m | 6W/m | 15W/m | |
| Typical CRI | 90 | 80 | 80 | |
| Module Length | 55.56mm | 83.33mm | 83.33mm | |
| Operating Temperature | -40 to 55 degrees Celsius | -40 to 55 degrees Celsius | -40 to 45 degrees Celsius | |
| Maximum Continuous Feed | 9m | 9m | 5m | |
| Input Voltage | 24VDC | |||
| IP Rating | IP20 | |||
| IK Rating | IK08 | |||
| Beam Angle | Approx. 115 degrees | |||
| Build Material | Silicone | |||
| Minimum Bend Radius | 150mm | |||
| Dimensions | 17mm (width), 16mm (height) | |||
| Weight | Approx. 0.36kg/m | |||
| Durability | UV, Saltwater, Solvent and Flame Resistant | |||
| Connector Options | IP20 Connector and End Cap | |||
| Mounting Options | Standard or Serrated Aluminium, Transparent Plastic or 3D Bending Silicone | |||
| Kit Length | 1m, 2m, 3m, 4m, 5m, 6m, 7m, 8m, 9m | |||
| Origin | International Partner | |||
InFlex
Flexible IP20 systems for interior applications
